Features
Direct airflow where you need it
180° MULTI-DIRECTIONAL AIR-OUTPUT CONTROL AT YOUR FINGERTIPS
Scag’s exclusive NDS (Nozzle Direction System) provides unprecedented control of the air-discharge vertical tilt and horizontal rotation.
Fingertip Switches
DUAL HORIZONTAL-ROTATION CONTROLS
Adjust the nozzle’s rotation up to 180 degrees using an Auto Left/Right Switch and a Fine-Tune Switch.
Convenient Manual Lever
VERTICAL-TILT CONTROL
Adjust the tilt of the discharge nozzle up to 16 degrees: lower to help loosen and blast stubborn debris or higher to prevent blowback.
Massive Air Output
6,000 / 7,500 CFM
Massive air output of up to 6,000 effective CFM (Cubic Feet per Minute) (7,500 theoretical peak CFM) provides incredible ground-clearing force on a variety of surfaces and applications.
Fabricated and Balanced, 23", 8-Blade Impeller
RELIABLE PERFORMANCE AND SMOOTH OPERATION
Heavy-duty blower construction ensures years of dependable service and worry-free performance. The 23″ steel, 8-blade impeller is dynamically balanced for smooth operation. The impeller mounting utilizes a tapered locking hub.
Large, Dual Air Intake
KEEP IT MOVING
Built with a front and rear air intake. Housing is aerodynamically designed to optimize intake without causing turbulence.
Controls and Instrument Panel
YOU'RE IN COMMAND
Proven, ergonomic drive-control lever’s design provides incredible ease-of-use. Instrument panel features NDS, ignition switch, PTO switch, throttle control, choke control and Scag’s exclusive Tiger Eye™ Advanced Monitoring System.
Operator Station
EXTRA-LARGE COMFORT CUSHION AND SUSPENSION PLATFORM
With an extra-thick cushion for operator comfort, the coil-suspension operator platform delivers an unmatched, ultra-comfortable ride. Tie-down points are built in to quickly secure to a trailer. Removable cushion and lower panel allow for quick and easy service access. Convenient engine and hydraulic oil drains are located underneath.
Powerful and Efficient Engine
HUGE POWER – 37 HP
Powered by a 37 hp Vanguard® BIG BLOCK™ EFI air-cooled engine for huge power, along with exceptional efficiency and dependable performance.
| Product Specification | Windstorm |
| Model | WS23-37BV-EFI |
| Total Fuel Capacity | 8 Gallons |
| Engine | Briggs Vanguard™ BIG BLOCK EFI |
| Horsepower | 37 HP |
| CFM Output | Effective CFM – 6,000 Theoretical Peak CFM – 7,500 |
| Electric Clutch | Ogura GT3.5 (250 ft lb) with Softstart Electric Clutch Control |
| Frame Construction | All-steel, welded 10-gauge |
| Impeller Construction | All-steel, welded, 8-blade, dynamically balanced |
| Impeller Mounting | Tapered locking hub |
| Impeller Diameter / Width | 23" / 8.5" |
| Blower Housing Construction | All-steel, welded, 12-gauge front and side housing plate and 10-gauge back housing plate |
| Blower Housing Width | 10" |
| Blower Tilt Angle | 16 degrees of total vertical tilt; 180 degrees of left/right horizontal rotation |
| Handlebar | n/a |
| Vibration Control | n/a |
| Discharge Opening | 69 square inches |
| Left / Right Discharge Control | Nozzle Direction System offers up to 180 degrees of rotation. |
| Discharge Angle Control | Yes – mechanical lever |
| Axle | n/a |
| Front Wheel(s) | 13" x 5"-6", flat-free |
| Rear Wheels | 24" x 12"-12", 4-ply |
| Accessories | Light Kit, Chrome Wheel Covers, Air Filter Monitor |
| Length | 71.5" |
| Width | 51" |
| Height | 47.25" |
| Weight | 943 lb |
